CRY602 Mouth Simulator
The CRY602 Mouth Simulator is used to simulate the sound source of the sound field near the mouth of a person.
Interested
For more information on CRY602 Mouth Simulator or to request a quote, contact our team now:
The CRY602 Mouth Simulator is suitable for the test of the acoustic parameters testing of telephones, headsets, in-ear devices with microphones, smart speakers, TV´s – any device with microphones used in voice communication.
The frequency response curve and other properties comply with the requirements of IEE 269, 661 and the requirement for ‘mouth referenced point’ for transmitting acoustic signals in ITU-T P51. It is a standard sound source for acoustic measurement.
Technical specifications of CRY602 |
|---|
| Min. continuous output SPL | 200 Hz – 10 kHz: 110 dB (@ 25mm MRP)
100 Hz – 10 kHz: 100 dB (@ 25mm MRP) |
| Distortion | 200 Hz – 10 kHz: ＜1.5%, generally ＜1%
(94 dB SPL @ 25 mm MRP) |
| Frequency response curve | Output sound pressure after compensation: 94 dB ±1 dB (100 Hz – 10 kHz) |
| Impedance | 4Ω |
| Max. continuous power | 10W |
| Max. instantaneous power | 50W（1s） |
| Sound aperture | Ø20mm |
| Lip ring | O.D.: Ø 51 mm
Height: 25 mm |
| Diameter | Ø100mm |
| Height | 88mm |
| Net weight | 1.3kg |
| Interface | BNC |
