CRY3202-S01 Measurement Microphone Set

The CRY3202-S01 is a 1/2-inch pressure-field prepolarized measurement microphone and preamplifier set designed to be used in conjunction with a coupler chamber for conducting relevant electroacoustic testing.

Crysound Logo

Interested

For more information on CRY3202-S01 Measurement Microphone Set or to request a quote, contact our team now:

request a quotecontact us
Laboratory application
Audiometry calibration application
Building Acoustics application
Ear Simulators

The CRY3202-S01 boasts a unique design that enables high-quality, wideband testing for in-ear monitors and earbuds. With a frequency range extending up to 20kHz, it surpasses the testing capabilities of most simulated ears, ensuring precise and comprehensive evaluations.

  • Full range pressure field microphone set
  • TEDS microphone set
  • Extensive compatibility
  • Durable, reliable and high-quality

CRY3202 Measurement Microphone

CRY3202 is suitable for high-frequency response and high sound pressure level measurements. It can perform tests such as headphone wideband testing. Easy to configure and user-friendly, making it highly suitable for production line use.

CRY3501 Preamplifier

The terminal connector for output is BNC which is convenient to connect to other instrument to input. It is characterized by high input impedance, low background noise and broadband sound range. It can be compatible with  ½  inch prepolarisation measurement microphone.

Unsure what measurement microphone best meets your requirements? Use our handy measurement microphone selection tool to discover which measurement microphone set is the best fit for you.

Technical Specification
Field TypePressure-field
Noominal Sensitivity12.5mV/Pa, -38±1.5dB re 1V/Pa
Frequency Response3.15Hz to 20kHz±2dB
Polarization Voltage0V
Dynamic Range23dBA to 147dB
Operating Temperature-30 to +70℃ (-22 to +158℉)
Temperature Stability0.005dB/℃(-10 to +50℃) 0.003dB/℉(+14 to +122℉)
Static Pressure Stability-0.01dB/kPa
Pressure Equalization VentRear vented
IEC 61094-4 TypeWS2P
Output Impedance< 20Ω
Maximum Output Voltage> 5.0Vrms
Current SourceIEPE (2mA to 10mA)
Typical Operating Current4mA
Interface TypeBNC
Height with Grid88.5mm (3.48″)
Diameter with Grid13.2mm (0.52″)
