CRY3101-S01 Measurement Microphone Set

The CRY3101-S01 is a 1-inch free-field prepolarized measurement microphone and preamplifier set, specifically designed for sensitive acoustic testing in low-noise environments such as anechoic chambers and quiet rooms.

Crysound Logo

Interested

For more information on CRY3101-S01 Measurement Microphone Set or to request a quote, contact our team now:

request a quotecontact us
Laboratory application

The unique design of CRY3101-S01 allows it to provide accurate and reliable acoustic measurement results, offering users excellent testing performance and flexibility. It is widely applicable in various domains, including acoustic testing, acoustic design research, and calibration testing of audio equipment including speakers and headphones.

  • Low noise free field microphone set
  • TEDS microphone set
  • Extensive compatibility
  • Durable, reliable and high quality

Unsure what measurement microphone best meets your requirements? Use our handy measurement microphone selection tool to discover which measurement microphone set is the best fit for you.

Technical Specification
Field TypeFree-field
Nominal Sensitivity50mV/Pa, -26±1.5dB re 1V/Pa
Frequency Response4Hz to 16kHz ±2dB
Polarization Voltage0V
Dynamic Range(re.20uPa)12dBA to 135dB
Operating Temperature-20 to +60℃ (-4 to +140℉)
Temperature Stability0.015dB/℃(-10 to +50℃) 0.008dB/℉(+14 to +122℉)
Static Pressure Stability-0.01dB/kPa
Operating Humidity Range0 to 90%RH no condensation
Humidity Stability< 0.1dB (0 to 90%RH no condensation)
Pressure Equalization VentRear vented
IEC 61094-4 TypeWS1F
Output Impedance＜25Ω
Maximum Output Voltage＞8Vp
Current SourceIEPE (2mA to 20mA)
Typical Operating Current4mA
Interface TypeBNC
Height with Grid94.3mm (3.712″)
Diameter with Grid23.77mm (0.936″)
